Category： Tanks & Vessels
Model：KFG-E
Feature： With multi-shaft stirrers, suitable for mixing low or high viscous materials. The each mixing shaft's speed can be controlled separately
Multi-functional mixing reactor is applied for materials mixing, homogeneous, grinding & reaction.
The vessel/reactor is made of high-quality stainless-steel.
Its inner and outer is mirror polished treatment.
The fittings have feeding/discharging system, clean system,-- etc..
The agitator includes anchor type, paddle type, propeller type, and it connects vessel by flange.
• With different capacity for optional.
• Mixer's motor power: 0.75kW - 110kW.
• Power supply: 380V, 50Hz, 3P or customized.
• Contacting parts' material: SUS304 or SUS316L stainless steel.
• Heating/coolings: can select heat oil / steam / hot water / cold water.
• Insulation material: cotton insulation / vesicant.
• Structure: upper and lower sealed head / flat lid type.
• Accessories: with quick opening manhole, valve and outlet, cleaning hole etc.
• Mixing agitator: paddle style, anchor style and propeller style for optional
• Fittings include: feeding/discharging hole, manual hole, --- etc
• We provide non-standard design, our engineer will design mixing reactor according to users' requirement.
The mixing blade (agitator) is driven by the power unit and rotated in a fixed direction.
During the rotation, the materials are driven to do axial rotation and radial rotation to achieve rapid mixings.
Materials inside the reactor are in both axial and circular motion, generating several forms of mixing such as shearing mixing and diffusion stirring. Thus the material can be effectively rapidly stirred and mixed.
Dispersion disc rotates in high speed, generating annular flow, resulting in strong vortex, thus the materials spirally down to the bottom.
Strong shearing and friction force between particles get the mixture rapidly dispersed and dissolved.
The circular motion of the stirring disc generates good radial effect, accelerating material circulation, improve the dispersing efficiency. Precision-engineered mixing workheads match with each other perfectly.
| Model | Capacity(L) | Agitator power(kw) | Speed(rpm) | Mixing blade(mm) | Materials |
| KFG-E-100 | 100 | 2.2 | 46 | 250 | SS304 or SS316L |
| KFG-E-200 | 200 | 4 | 46 | 350 | SS304 or SS316L |
| KFG-E-300 | 300 | 5.5 | 46 | 350 | SS304 or SS316L |
| KFG-E-500 | 500 | 7.5 | 46 | 380 | SS304 or SS316L |
| KFG-E-1000 | 1000 | 11 | 43 | 400 | SS304 or SS316L |
| KFG-E-2000 | 2000 | 15 | 43 | 450 | SS304 or SS316L |
| KFG-E-3000 | 3000 | 22 | 43 | 500 | SS304 or SS316L |
| KFG-E-5000 | 5000 | 30 | 43 | 600 | SS304 or SS316L |
| KFG-E-6000 | 6000 | 37 | 35 | 650 | SS304 or SS316L |
| KFG-E-8000 | 8000 | 45 | 35 | 700 | SS304 or SS316L |
| KFG-E-10000 | 10000 | 55 | 35 | 800 | SS304 or SS316L |
This model is suitable to do the materials of viscosity below 500,000 cps.
Production Capacity: 0~12,000L.
Applied materials: suitable for liquid or liquid-phase's high speed stirring, dissolving and scattering in the field of coating, paint, dye, printing ink, paint, cosmetics, resin, adhesive, latex, pharmaceutical, oil, powder, etc.
